SITRANS TH200

  • OVERVIEW
    • SITRANS TH200

      The universal

      Description

      SITRANS TH200 is designed to support all common RTDs, thermocouples, resistance and millivolt-sensors. Setup is quick and easy with the transmitter-modem and SIPROM T software. This configuration tool can be downloaded free. Unique user-friendly details are implemented: Without opening the 4-..20mA loop, the output current can read directly with a multimeter. A red/green LED shows the technician the status at a glance.



      Benefits

      • -Measures temperature with a linear output signal
      • -high accuracy across entire ambient temperature range
      • -reduces plant noise
      • -Alarm signal for sensor break or short-circuit according NAMUR 43
      • -Electro magnetic compatibility (EMC) according DIN EN 61326 and NE21
      • -Saves expensive compensation cables with the internal reference junction
      • -Galvanic insulation for accuracy and safety in thermocouple applications
      • -Single- or dual-point trim
      • -Custom characteristic curve for application of non-standard sensors
      • -Difference- and average- measurement
      • -Explosion protected executions for US, Canada and Europe
      • -Rugged design, fully potted electronics

  • SPECIFICATION
    • Detail

      Input Resistance thermometers, Thermocouples, Resistance-type sensors, DC sources
      Output 4 to 20 mA
