    • SITRANS Lh300



      Description

      The SITRANS Lh300 series pressure transmitter converts the level-proportional hydrostatic pressure into a standardized signal 4 to 20 mA. The transmitter consists of a stainless steel housing (Ø 23,4 mm) with mechanical protection IP 68, a piezo-resistive sensor with ceramic diaphragm. The transmitter cable has a diameter of Ø 6 mm and also contains a vent pipe for connection to the atmosphere.

      Benefits

      • Compact design
      • Corrosion resistant material
      • housing: stainless steel 316L
      • cable: sheath made of PE
      • cable length: standard 10, 20 or 30 m, special length up to 50 m possible
      • Explosion protected version acc. ATEX II 1 G Ex ia IIC T4 Ga and IEC Ex Ex ia IIC T4 Ga available

      Standard measuring set:

      • Transmitter
      • Cable hanger
      • Junction box

  • SPECIFICATION
    • Detail

      Accuracy 0,3%
      Long-Term stability 0,25%/12 months
      Measuring range 0 – 4 mH2O (0 – 13,2 ftH2O) to 0 - 20m H2O (0 – 66 ftH2O)
